Welding Materials : PVC / Flex / Banner / Plastic and other materials can be hot melt
Moving,Dismantlement,Installation,Cleaning:
► Any part of this machine being bumped of fallen can cause some damage impossible to be repaired.So please pay attention to carry it.It is suggested to move the machine by manpower and put it down carefully
► The place for installation must be flat and the floor is strong enough to support the machine and moreover, the installation place should close to power supply
► Please check if there is damage or missed parts after unpack the machine.Any problem, please contact us or the local agent immediately
► Please sweep away the anti-rust oil from the machine with detergent and re-lubricate with light lubricating oil after installation
► Keep the installation place no dust and avoiding sunshine
| Connecting the power supply:
Connecting the electric wire to the reserved plug(AC220V)of controlling box. |
Take care the nozzle.Use brush to clean if there is dust or block in the nozzle or filter. |
Operation Step :
1. Make the cloth for seaming flat and put it underneath.Fix both ends by adhesive tape or something else.
2.The overlap width of the two pieces is about 3-mm, the width of the nozzle of hot seaming machine.
3.Put the machine nozzle between two overlap pieces.The press-wheel should be at left side of nozzle.The nozzle also need align with side of upper piece of cloth.
4. Switch on the motor power and then adjust speed.
5.Turn on the movement switch.
6.Press heating power key to adjust temperature.
7.Turn the bar by anticlockwise to fix the position to startup automatic movement.The machine will go along with the overlap path by itself.
8.Turn the bar by clockwise to cease the automatic work.
9.The operator should control the moving direction and make sure the nozzle connect both with upper and under piece of cloth
| General instruction for safety :
♦ Keep the working place clean. Messing up and the disorderly working place cause disaster ♦ Choose the work place carefully and use the machine in a bright and dry circumstance. ♦ For safety and the long life of the machine, please do not let the machine operates overtime. ♦ The electricity, controlling box and protective facilities have to be in the proper order after finishing daily work. The electrical power supply has to be switched off definitely. ♦ The machine has to be stopped before gets maintenance or replacing the parts. ♦ Use standard or indicated tools when dismantling or replacing parts. ♦ If any special incidents happened, please stop the machine first for repairing, And do not deal with the special incident with improper procedures. ♦ If the machine is operated on land, keep the work place clean and no dust there. If dust or something blocks the inhaling filter of heater, the heating wind can not come cut adequately and then temperature inside of filter will rise to let the heater burn down. |
| Operation Notice :
♦ During operating, if the surface cloth is dissolved and scorched or the cloth are not sticked together, please stop to adjust the temperature or speed. ♦ During operating,if the seaming part is not in right position, please stop to adjust fixing position. ♦ Adjust temperature to zero before turn off the heater.Switch off after 5-10 minutes ♦ During operating, make sure clothes are flat so that stick together smoothly. ♦The hot wind of heater cannot touch the press-wheel or the rubber of press-wheel is easy to be burned down. |
FAQ :
1. Q : What is the use of the machine ?
A : Use hot air to make the PVC Banner welding together
2. Q : What kinds of materials can it welding ?
A : It can welding PVC / Banner / Flex and other outdoor materials can be hot melt
3. Q : What's the machine work type ?
A : It's Automatic welding
4. Q : Which kinds of hot air gun it use ?
A : Leister hot air gun
5. Q : How long is the warranty period?
A : The Warranty is one year
6. Q : What's the MOQ ?
A : The MOQ is One set of Welding machine
Company Information :
Shen Zhen Ming Yang Digital Technology Co.,Ltd
We are a professional Export Trade Company ,With 7 years experience , Sale many kinds of machine and materials about the Advertising Industry .
We assure you :
With good quality Banner welding machine
Offer best price to you
Arrange the fast delivery
Provide good after-sales service
