50 HZ Automatic Flex Vinyl Banner Welding Machine 2 - 4 Mm Width 5 - 15 M / Min

Product Categories

Shenzhen Mingyang Digital Technology Co.,Ltd

Contact Now

50 HZ Automatic Flex Vinyl Banner Welding Machine 2 - 4 Mm Width 5 - 15 M / Min

Name: 50 HZ Automatic Flex Vinyl Banner Welding Machine 2 4 Mm Width 5 15 M Min
Brand: MingYang
Price: 1 USD

Brand Name : MingYang

Model Number : MY-BW-A

Certification : CE

Place of Origin : China,GuangDon

MOQ : 1 set

Price : indeterminate

Payment Terms : Western Union, MoneyGram, T/T,Paypal

Supply Ability : 9889 sets / month

Delivery Time : 2-5 working days

Packaging Details : size : 49*25*20cm ; weight : 15kg ; pcakage : carton box

Machine name : Banner Welding Machine

power : 1800W

Voltage : 110V / 220V

Welding width : 2-4mm

Welding thickness : 0.2-2mm

temperature scope : 20-500 degree

Speed : 5-15m/min

weight : 15kg

size : 49*25*20cm

package : carton box

Warranty : one year

MOQ : one set

Contact Now

Automatic Welding Of Flex Banner Welding Machine /

Plastic Welder Machine

Application field :

►Use for weld PVC, PE and other material can be hot melt, like flex, PVC cloth etc

Advantage :

►No need glue, use hot air to weld

►Temperature, speed, fan motor speed are adjustable

►Welder nozzle has a sensor, can make the true temperature accurately

►High welding quality

Main technical details :

►Rated voltage: AC110-240V

►Frequency: 50-60HZ

►Power: 1000-3000W

►Temperature scope: 0-500℃

►Speed scope: 1-15m/min

►Dimension: 41*25*20c

►Weight: 15kg

►Splicing width: 2-5cm

►Welding Thickness: 0.22-2mm

►Welding width: 2-4cm

►Welder cable: 10 meters

►Welder wheel: Aluminum wheel

Operation Step :

step 1	Before hemming or welding, leave 30-40mm wide overlap edge for connection the two disjunct surface pieces, immobilize both ends of each disjunct pieces with something such as stick belt or clamp
step 2	Turn on the power, according to quality and thickness of the PVC banner, consider the ground circumstance, set the proper termperature and speed, adjust the suitable hot-air blowing rate, wait for machine hot up around 2 minutes
step 3	Bring up the machine, place the rubber wheel at the end of the overlap edge
step 4	Turn the handle to left down, insert the welder nozzle into the gap of two overlap pieces, then the machine will moving and seaming automatic
step 5	During welding, use the gripe to align the moving direction, let the upper piece edge be in touch with the inner side of the welder nozzle
step 6	After the machine go pass the overlap edge to the end, the two disjunct pieces will be joined together, then turn the welder handle to right, it will stop moving
step 7	Turn off the heater switch, wait the gun come to cold, then turn off the power supply is ok

Notice:

►To prolong the electrothermal heater, after work it is strongly advice that cooling the heater at first, then turn off the power 5 minutes later. In case of the power suddenly be off, should handle the welding gun away firstly, and close down the temperature knob, nextly consider the problem of power supply.

►To get better satisfied bonding effect, the ground of the overlap pieces should be smoothly, hard and heat resistive. We suggest that the operator may do some more test and practice using some samples of the pieces to get the suitable speed and temperature and hot-air blowing rate before operate it for seaming formally

FAQ :

1. Q : What's the Function ?

A : The Function is : Welding PVC / Flex Banner , Plastic and other materials can be hot melt .

2. Q : What's the MOQ ?

A : The MOQ is one set of Welding Machine .

3. Q : Is it automatic work ?

A : yes , It is automatic welding .

4. Q : How long is the warranty period ?

A : The warranty is one year .

5. Q : How can i pay ?

A : Our company accept : T/T , Western union , Paypal .

Please send your Inquiry Details at the below , Thank you !
